An update to the 9564S, the XRC6864s brings revised compressor aero, cover updates, and more power for the 68mm class.
- Compressor wheel - 68mm Inducer / 94mm Exducer
- Turbine Outlet - 64mm
- 105lb/Minute Flow Rating
- 550-950HP Applications
- Variable preload angular contact bearings
- Twin gas ring seals at the compressor and turbine
- High strength, lightweight stainless steel center housing
- Full hydraulic damping of the rotating assembly
- Integrated oil contaminate filter
- M62 race material allows higher temperature operation
- Metallic bearing cages
Product Information
The revolutionary UHF™ aero XR64S turbine delivers the greatest overall flow possible while simultaneously reducing inertia more than 30% giving the fastest response we have ever observed at this power level.
This turbocharger is available in an X3C cover, dimensions for this cover is included in the product images.
